What you’ll learn

  • How to do PLC programming with FBD (Function Block Diagram)
  • What are input and output signals for programming
  • What constants and variables mean for programmer
  • How to treat digital output (DO) signals with PLC
  • How to configure alarms with PLC
  • How to deal with analog output (AO) signals with PLC
  • How to use PID controllers with PLC
  • What interlocks mean and how to configure them
  • What interface signals and how to generate them
  • How to handle a starting order among many devices
  • What the re-circulation mode is and how to configure the PLC program for it


  • Basic understanding for the HVAC system

This lecture includes all knowledge and know-how I have gotten while working as a HVAC engineer since 2009. I tried to explain as much as I can about the new and best tactics used in the actual field. So, I organized agenda useful for not only beginners but experts who know almost everything about systems of HVAC (Heating, Ventilating and Air-Conditioning) except for the automatic control. For example, you can feel that they are my daily issues I need to handle while working as an engineer or a technician in the HVAC field after checking the topics.

I did my best to explain about the PLC (Programmable Logic Controller) program as easy as possible with minimum functions. I bet that this lecture will be incredibly helpful for you not only when you reviewing the others’ program but also making your own program.

You will understand about the below after this lecture.

  • What input and output signals are and how to use them for PLC programming
  • What constants and variables are and how to handle them
  • A way to deal with digital output signals for AHU (Air Handling Unit), ACCU (Air Cooled Condensing Unit), Fan, Pump, Chiller, EDH (Electric Duct Heater), EHU (Electric Humidifier), motorized dampers/valves and so on.
  • A procedure for configuring alarms with PLC program
  • How to deal with VFD (Variable Frequency Drive) AHU with a PID controller
  • A way to operate TCV (Temperature Control Valve) with a PID controller
  • What interlock signals mean and how to configure them with PLC program
  • How to configure interface signals
  • How to operate many devices or equipment with a specific order
  • How to build programs for special functions like re-circulation mode

I hope you will enjoy your program work after taking lecture. And if you have any topic you want me to explain, please let me know through feedback or email. Good luck.

Who this course is for:
  • Students who are majoring automation
  • Beginner level engineers handling the HVAC system
  • Students who want to know the practical programming for the automatic systems
  • Anyone who wants to understand the PLC programming and its simulation
  • Engineers who want to understand about the automatic program further
  • Someones willing to work for the HVAC field
  • Engineers who need to manage outside research and development companies
